28
Setting up the monitor
Removing the monitor stand
NOTE: To prevent scratches on the LCD screen when removing the stand, ensure that the monitor is placed on a soft surface and
handle it carefully.
NOTE: The following steps are specific for removing the stand that is shipped with your monitor. If you are removing a stand that you
purchased from any other source, follow the setup instructions that are included with the stand.
NOTE: Before removing the stand, ensure that you have disconnected all the cables from the monitor. To remove the stand:
1. Place the monitor on a soft cloth along the desk.
Figure 18. Place the monitor on the desk
2. Use a screwdriver to loosen the two screws at the top of the stand.
Figure 19. Remove the screws of the stand
3. Push the release button.
Figure 20. Push the release button
