30
Setting up the monitor
VESA wall Mounting (Optional)
Figure 22. VESA wall Mounting
(Screw dimension: M4 x 10 mm).
See the instructions that come with the VESA-compatible base mounting kit.
1. Place the monitor panel on a soft cloth or cushion on a stable flat table.
2. Remove the stand.
3. Remove the four screws from the wall hanging hole.
4. Attach the mounting bracket from the wall mounting kit to the LCD.
5. Mount the LCD
on the wall by following the instructions that came with the base mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall-mount bracket with minimum weight/load bearing capacity of 21.26 kg (47.53
lb) for G2725D.
Using tilt
You can tilt the monitor for the most comfortable viewing angle.
NOTE: The stand is not attached when the monitor is shipped from the factory.
Figure 23. Tilt adjustment
