Dell™OptiPlex™760ServiceManual
System Fan
System Fan
Removing the System Fan
1. Follow the procedures in Working on Your Computer.
2. Remove the computer cover (see Removing the Computer Cover).
3. Remove the heat sink assembly and processor (see Removing the Processor).
4. Remove the system board (see Removing the System Board).
5. Disconnect the diagnostics lights cable from the fan assembly.
6. Press the tab that secures the fan to computer chassis and push the fan away from the computer chassis.
7. Lift the system fan up and away from the computer.
Installing the System Fan
To replace the fan, follow the removal procedures in the reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
