NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
NanoSIM-card tray
Removing the nanoSIM-card tray
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
NOTE: This procedure applies only to computers shipped with a nanoSIM-card tray installed. No pre-removals for models
shipped without WWAN antennas.
The following images indicate the location of the nanoSIM-card tray and provide a visual representation of the removal
procedure.
Steps
1. Insert a pin into the release hole of the nanoSIM-card tray and push inward until the tray is released.
2. Slide the nanoSIM-card tray out of the slot on the computer.
3. Remove the SIM card from the nanoSIM-card tray.
4. Slide the nanoSIM-card tray into the slot, until it clicks into place.
Installing the nanoSIM-card tray
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
Removing and installing components
13
