6. Remove the heat-sink.
7. Remove the speakers.
8. Remove the I/O daughter-board.
9. Remove the Power button.
10. Remove the system board.
NOTE: When removing the system board to replace or access other parts, the system board can be removed and
installed with the heat sink attached to simplify the procedure and preserve the thermal bond between the system board
and heat sink.
About this task
The following images indicate the location of the keyboard and provide a visual representation of the removal procedure.
Removing and installing components 63
