Wireless module
The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Latitude 7450.
Table 10. Wireless module specifications
Description Values
Model number
Intel BE200 (integrated on system board)
Transfer rate
5760 Mbps
Frequency bands supported
2.40 GHz/5 GHz/6 GHz
Wireless standards
● WiFi 802.11a/b/g
● Wi-Fi 4 (WiFi 802.11n)
● Wi-Fi 5 (WiFi 802.11ac)
● Wi-Fi 6E (WiFi 802.11ax)
● Wi-Fi 7 (WiFi 802.11be)
Encryption
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
Bluetooth wireless card
Bluetooth 5.4 wireless card
NOTE: The version of the Bluetooth wireless card may
vary depending on the operating system that is installed
on your computer.
WWAN module
The following table lists the Wireless Wide Area Network (WWAN) module supported on your Latitude 7450.
Table 11.
WWAN module specifications
Description Option one Option two
Model number DW5825e (FM101R-GL), Qualcomm
Snapdragon X12 global LTE-Advanced,
CAT12
DW5932e, 5G, Qualcomm Snapdragon
X62 Global 5G Modem
Form Factor M.2 3042 Key-B M.2 3042 Key
Host Interface PCIe Gen2 PCIe Gen3
Network Standard LTE FDD/TDD, WCDMA/HSPA+, GPS/
GLONASS/BDS/Galileo
LTE FDD/TDD, WCDMA/HSPA+, GNSS/
Beidou NR FR1 (Sub6) FDD/TDD,
LTE FDD/TDD, WCDMA/HSPA+, GPS/
GLONASS/Galileo/BDS/QZSS
Transfer data rate
● Up to 1 Gbps DL (Cat 12)
● Up to 150 Mbps UL
● SA: DL 4.67 Gbps/UL 1.25 Gbps
● NSA: DL 3.74 Gbps/UL 700 Mbps
● LTE: DL 1.6 Gbps (CAT19)/UL 150
Mbps
● UMTS: DL 384 kbps/UL 384 kbps
DL DC-HSPA+: 42 Mbps (CAT24)/UL
11.5 Mbps (CAT7)
Specifications of Latitude 7450 23
