Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the WWAN card.
NOTE: This procedure applies only to computers shipped with a WWAN card installed.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
Figure 48. Removing the display assembly
78
Removing and installing Field Replaceable Units (FRUs)
