About your monitor
RJ45 connector LED status:
Left LED
Right LED
Figure 12. RJ45 LED color
Table 26. RJ45 LED color.
LED Color Description
Right LED Amber or Green Speed indicator:
• Amber On - 1000 Mbps
• Green On - 100 Mbps
• Off - 10 Mbps
Left LED Green Link/Activity indicator:
• Blinking - Activity on the port.
• Green On - Link is being established.
• Off - Link is not established.
NOTE: RJ45 cable is not a standard in-box accessory.
Plug-and-play capability
You can connect the monitor to any Plug and Play-compatible system. The monitor automatically provides the computer with its
Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so that the computer can configure itself
and optimize the monitor settings. Most monitor installations are automatic; you can select different settings as required. For more
information about changing the monitor settings, see Operating the monitor.
LCD monitor quality and pixel policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more pixels to become fixed in an unchanging state
which are hard to see and do not affect the display quality or usability. For more information on Dell Monitor Quality and Pixel Policy,
see Dell Display Pixel Guidelines.
