Setting up the monitor
VESA wall mounting (optional)
Figure 56. VESA wall mounting
NOTE: Use M4 x 10 mm screws to connect the monitor to the wall-mounting kit.
See the instructions that come with the VESA-compatible wall mounting kit.
1. Place the monitor on a soft cloth or cushion on a stable flat table.
2. Remove the stand (See Removing the monitor stand).
3. Using a Phillips crosshead screwdriver, remove the four screws securing the plastic cover.
4. Attach the mounting bracket from the wall-mounting kit to the monitor.
5. Mount the monitor on the wall. For more information, see the documentation that shipped with the wall-mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with minimum weight or load bearing capacity of 26.52 kg
(58.47 lb) (P3225DE)/26.60 kg (58.64 lb) (P3225QE).
