Component Secured to Screw type Quantity Screw image
Optical-drive interposer Palm rest and keyboard
assembly
M2x2 Big Head 2
Panel Display back-cover and
antenna assembly
M2x3 4
Power-adapter port Palm rest and keyboard
assembly
M2x3 1
Power-button board Palm rest and keyboard
assembly
M2x3 1
System board assembly Palm rest and keyboard
assembly
M2x3 3
Touch pad Palm rest and keyboard
assembly
M2x2 4
Touch-pad bracket Palm rest and keyboard
assembly
M2x2 3
Wireless-card bracket System board assembly M2x3 1
10 Before working inside your computer
