Removing the display bezel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
NOTE: These instructions are only applicable for laptop with non-touchscreen display.
1. Remove the optical drive.
2. Remove the base cover.
3. Remove the battery.
4. Remove the wireless card.
5. Remove the display assembly.
Procedure
1. Using a plastic scribe, carefully pry up the display bezel.
2. Remove the display bezel off the display back-cover.
a. display bezel
b. display back-cover
39
68 Removing the display bezel
