Removing the display panel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
NOTE: These instructions are applicable only for laptops with a non-touch screen display.
1. Remove the optical drive.
2. Remove the base cover.
3. Remove the battery.
4. Remove the wireless card.
5. Remove the display assembly.
6. Remove the display bezel.
Procedure
1. Remove the screws that secure the display panel to the display back-cover.
2. Gently lift the display panel and turn it over.
a. display back-cover
b. display panel
41
Removing the display panel 71
