Removing the optical-drive interposer
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1. Remove the optical drive.
2. Remove the base cover.
3. Remove the battery.
Procedure
1. Lift the latch and disconnect optical-drive connector board cable from the optical-drive board connector.
2. Remove the screws that secure the optical-drive connector board to the palm rest and keyboard assembly.
3. Lift the optical-drive connector board off the palm rest and keyboard assembly.
1.
optical-drive connector board 2. M2x2 screws (2)
3. latch 4. optical-drive connector board cable
25
46 Removing the optical-drive interposer
