Removing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1. Remove the optical drive.
2. Remove the base cover.
3. Remove the battery.
Procedure
1. Disconnect the speaker cable from the system board.
2. Note the speaker-cable routing on the palm rest and keyboard assembly and release the cable from the routing guides.
3. Lift the speakers, along with the speaker cable, off the palm rest and keyboard assembly.
1.
speaker cable 2. speakers (2)
19
Removing the speakers 37
