Dell P74F - Installing the Battery

Installing the battery
1. To install the 6-cell battery:
a. Place the battery onto its slot in the system [1].
b. Replace the 3 (M2.5x3.0) screws to secure the battery to the system [2].
c. Connect the battery cable to the connector in the battery [3].
Removing and installing components
21
