2. Install the:
a. battery
b. base cover
c. SD card
3. Follow the procedure in After working inside your computer.
Smart card cage
Removing the smart card cage
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. SD card
b. base cover
c. battery
d. keyboard
e. hard drive
f. palmrest
3. To remove power switch board:
a. Disconnect the smart card cage cable from the connector on the palmrest board [1].
b. Pry the smart card cage cable.
c. Remove the 2 (M2.0X3.0) screws that secure the smart card cage to the palmrest [3].
d. Remove the smart card cage from the palmrest [4].
58
Removing and installing components
