Screw size list
Table 2. Precision 7540
Component Screw type Quantity Image
Keyboard
M2.0x2.0
6
SSD thermal plate
M.2 SSD card
HDD Interposer board
WLAN card
WWAN
eDP bracket
Display panel
Power button board
Smart card cage
FPC beam connector
Palmrest
Display support bracket
Power daughter-board
M2.0x3.0
1 per SSD
1 per SSD
2
1
1
2
4
1
2
2
4
6
3
System board
Palmrest
Type-C bracket
LED board
Power connector port
GPU card
M2.0x5.0
3
11
3
1
1
2
4 Cell Battery
6 Cell Battery
HDD assembly
M2.5x3.0
2
3
4
Display hinge
M2.5x3.5
6
Hinge cap
Display assembly (bottom)
M2.5x4.0
4
2
Display assembly (rear)
M2.5X6.0
2
HDD bracket
M3.0x3.0
4
