2. Install the:
a. battery
b. base cover
c. SD card
3. Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. SD card
b. base cover
c. battery
3. To remove the WLAN card:
a. Remove the single (M2.0x3.0) screw that secures the WLAN metal bracket to the system board [1].
b. Remove the WLAN metal bracket that secures the WLAN antenna cables [2].
c. Disconnect and un-route the antenna cables connected to the WLAN card [3].
d. Remove the WLAN card from the WLAN card slot in the system board [4].
34
Removing and installing components
