Dell P75F - Page 16

Component Secured to Screw type Quantity Screw image
Hinges Palm rest and keyboard
assembly
M2.5x5 5
Hinge brackets Display back-cover and
antenna assembly
(M2.5x4) 8
Hinge brackets Display back-cover and
antenna assembly
M2x2 2
I/O board Palm rest and keyboard
assembly
M2x4 2
Power-adapter port Palm rest and keyboard
assembly
M2x3 1
Power-button board Palm rest and keyboard
assembly
M2x2 1
Power button with
ngerprint reader
(optional)
Palm rest and keyboard
assembly
M2x2 1
Solid-state drive/Intel
Optane
Palm rest and keyboard
assembly
M2x2.2 1
System board Palm rest and keyboard
assembly
M2x4 1
Touchpad Palm rest and keyboard
assembly
M2x2 4
Wireless-card bracket System board M2x3 1
16 Screw list
