Removing the power-button board
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-8F605C1C-7CD6-4EE8-93E7-C810E6793F7C
Status Released
Prerequisites
1 Remove the base cover.
2 Remove the fan.
Identifier GUID-4B7FF860-E101-4C78-86C3-860CD80E14E1
Status Released
Procedure
1 Remove the three screws (M2.5x5) that secure the left hinge to palm rest and keyboard assembly.
2 Open the left hinge.
3 Open the latch and disconnect the power-button board cable from the system board.
4 Peel o the tape that secures the power-button board to the palm rest and keyboard assembly.
34
Removing the power-button board 69
