Removing the display assembly
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-418DE02A-7069-48EE-9C00-815AD58579F4
Status Released
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
Identifier GUID-B220E67E-99E6-4990-B767-C93E38815669
Status Released
Procedure
1 Open the latch and disconnect the display cable from the system board.
2 Note the routing of the display cable and remove the cable from its routing guides on the fan and palm rest and keyboard assembly.
30
60 Removing the display assembly
