About Your System 15
Hard-Drive Indicator Codes
The hard-drive carriers have two indicators—the drive-activity indicator and the drive-status indicator. See
Figure 1-2. In RAID configurations, the drive-status indicator lights to indicate the status of the drive. In
non-RAID configurations, only the drive-activity indicator lights; the drive-status indicator is off.
Figure 1-2. Hard-Drive Indicators
1 drive-status indicator (green
and amber)
2 green drive-activity indicator
1
2
