Figure 32. Removing and installing a processor heat sink
1. captive screw (4) 2. heat sink
3. processor socket 4. slot (4)
CAUTION: The processor is held in its socket under strong pressure. Be aware that the
release lever can spring up suddenly if not firmly grasped.
85
