Dell PowerEdge T30 - Chassis Weight; Processor Specifications; PSU Specifications; System Battery Specification

Chassis weight
Table 11. Chassis weight
System Maximum weight (with all hard drives/SSDs)
PowerEdge T30
11.70 kg (25.70 lb)
Processor specifications
The PowerEdge T30 system supports the following processors:
• Intel Xeon E3-1200 v5 processor
• Intel Core i3 series processor
• Intel Pentium processor
PSU specifications
The PowerEdge T30 system supports a single 290 W AC cabled power supply unit (PSU).
Table 12. PSU specifications
PSU Heat dissipation (maximum) Frequency Voltage
290 W AC 989.00 BTU/hr 50 – 60 Hz 100 – 240 V AC, 5.4 A, autoranging
NOTE: Heat dissipation is calculated by using the PSU wattage rating.
NOTE: The PowerEdge T30 system is also designed to connect to the IT power systems with a phase-to-phase voltage not
exceeding 230 V.
System battery specification
The PowerEdge T30 system supports CR 2032 3.0-V lithium coin cell system battery.
Expansion bus specifications
The PowerEdge T30 system supports PCI express (PCIe) generation 3 expansion cards, which must be installed on the system board. The
following table provides detailed information about the expansion card specifications:
Table 13. Expansion card specifications
PCIe slot Height Length Link
1 Full height Half length x16
3 Full height Half length x4
4 Full height Half length x4
NOTE: Slot 2 is a full-height, half-length PCI 32/33 card slot connected to PCIe and PCI Bridge.
Memory specifications
The PowerEdge T30 system supports up to four 2133 MT/s (ECC) and 2400 MT/s (Non-ECC), single rank or dual rank UDIMMs.
