Jumpers and connectors
This topic provides specific information about the system jumpers. It also provides some basic information about jumpers and switches and
describes the connectors on the various boards in the system. Jumpers on the system board help to disable system and setup passwords.
You must know the connectors on the system board to install components and cables correctly.
Topics:
• System board connectors
• System board jumper settings
• Disabling forgotten password
System board connectors
Figure 52. System board connectors
