Table 38. System board connectors
Item Connector Description
1 SLOT4 PCI Express x16 slot (wired as x4)
2 SLOT3 PCI Express x4 slot
3 SLOT2 PCI slot
4 SLOT1 PCI Express x16 Gen 3 slot
5 R_USB3
USB 3.0 connector
6 HDMI
HDMI connector
7 SERIAL
serial port connector
8 DP_PORT1DP_PORT2
2 x Display port
9 NIC_USB
USB 2.0 with Network connector
10 KYBD_MOUSE
keyboard/mouse connector
11 INTRUDER
intrusion switch connector
12 ATX_CPU
P2 power connector
13 FAN_SYS
System fan connector
14 CPU
CPU socket
15 FAN_CPU
CPU fan connector
16 BATTERY
coin cell battery
17 DIMM slots
Memory slot
18 F_PANEL1
front power switch connector
19 ATX_SYS_1
8-pin power connector
20 SATA1
SATA 1 connector
21 SATA2
SATA 2 connector
22 SATA_PWR
HDD_ODD_Power cable connector
23 F_USB4
USB 3.0 connector
24 SATA0
SATA 0 connector
25 F_USB3
Front I/O panel connector
26 SATA3
SATA 3 connector
27 PSWD
password reset jumper
28 SERVICE_MODE
Service_Mode Jumper connector
