Jumpers and Connectors 171
Table 6-2. System Board Jumpers and Connectors
Item Connector Description
1USB1
USB2
USB3
USB4
External USB connector 1
External USB connector 2
External USB connector 3
External USB connector 4
2 NIC1 External NIC connector 1
3 NIC2 External NIC connector 1
4 VGA External Video connector
5 COM External Serial connector
6 FAN Fan connector
7 iDRAC6 Enterprise iDRAC6 Enterprise card connector
8 PCIE_X8 PCIe connector x8 (slot 1)
9 PCIE_X16 PCIe connector x16 (slot 2)
10 PCIE_X8 PCIe connector x8 (slot 3)
11 PCIE_X1 PCIe connector x1 (slot 4)
12 PCIE_X1 PCIe connector x1 (slot 5)
13 PWRD_EN
NVRM_CLR
Password enable jumper
NVRAM clear jumper
14 BATTERY System battery
15 SATA_D SATA connector D
16 SATA_C SATA connector C
17 SATA_B SATA connector B
18 SATA_A SATA connector A
19 SATA_F SATA connector F
20 INT_USB 2 Internal USB module connector 2
21 SATA_E SATA connector E
22 INT_USB 1 Internal USB module connector 1
