Figure 13. 10 x 2.5-inch Universal backplane
Figure 14. 10 x 2.5-inch NVMe backplane (48 mode)
Component installation guidelines
17

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell PowerFlex Custom Node R6525 and is the answer not in the manual?

Dell PowerFlex Custom Node R6525 Specifications

General IconGeneral
ProcessorUp to 2x AMD EPYC 7002/7003 series processors, up to 64 cores per processor
Memory32 DDR4 DIMM slots
Drive BaysUp to 24 x 2.5" SAS/SATA (HDD/SSD)
RAID SupportPERC H745P
Networking1GbE, 10GbE, 25GbE
Power Supply1100W Platinum
