Dell PowerFlex Custom Node R6525 User Manual

Figure 17. 10 x 2.5-inch SAS with 2 x 2.5-inch NVMe drive
Figure 18. 8 x 2.5- inch NVMe RAID
Drive backplane
Depending on your system configuration, the drive backplanes supported are listed here:
Table 7. Supported backplane options
System Supported drive options
PowerFlex custom node R6525 2.5-inch (x8) SAS or SATA backplane
Component installation guidelines 19

Dell PowerFlex Custom Node R6525 Specifications

General

Processor	Up to 2x AMD EPYC 7002/7003 series processors, up to 64 cores per processor
Memory	32 DDR4 DIMM slots
Drive Bays	Up to 24 x 2.5" SAS/SATA (HDD/SSD)
RAID Support	PERC H745P
Networking	1GbE, 10GbE, 25GbE
Power Supply	1100W Platinum
