Table 16. Configuration 6: R1D+R2A+R3A (continued)
Card Type Supplier Category Card Priority Slot Priority
CRD,NTWK,BCME,OCP
3,25G,2P,S28
Broadcom OCP: 25Gb 8400 INT
CRD,NTWK,OCP3,BCM
E,10/25G,4
Broadcom OCP: 25Gb 8500 INT
CRD,NTWK,MLNX,OCP
3,25G,2P,S28
Mellanox OCP: 25Gb 8700 INT
CRD,NTWK,BCME,OCP
3,10G,2P,BT
Broadcom OCP: 10Gb 9200 INT
Table 17. Configuration 7: R1D+R2B+R3A
Card type Supplier Category Card Priority Slot Priority Bracket Height
Allowed
Max # of
Cards
CRD,GRPHC,NV
IDI,T4,16GB,70
W,V2
Nvidia GPU 100 Not supported FH 0
CRD,GRPHC,NV
IDIA,T4,16GB,70
W,L
Nvidia GPU 200 3 LP 1
ASSY,CRD,CTL,
H745,4GB,FPER
C,V2
INVENTEC Front PERC 300 INT NONE 1
ASSY,CRD,CTL,
H745,4GBNV,F
PERC
INVENTEC Front PERC 400 INT NONE 1
ASSY,CRD,CTL,
H345,FPERC,V2
FOXCONN Front PERC 500 INT NONE 1
ASSY,CRD,CTL,
H345,FPERC
FOXCONN Front PERC 600 INT NONE 1
PWA,CTL,HBA3
45,FRONT
FOXCONN Front PERC 700 INT NONE 1
PWA,CTL,HBA3
45,FRONT,V2
FOXCONN Front PERC 800 INT NONE 1
CRD,NTWK,100
G,CX5,DP,QSFP
,MLNX
Mellanox NIC: 100Gb 1000 Not supported FH 0
CRD,NTWK,100
G,CX5,DP,QSF,
MLX,L
Mellanox NIC: 100Gb 1100 2, 1, 3 LP 3
CRD,CTL,PCIE,
EDR,CX5,SP,L,
MLNX
Mellanox NIC: 100Gb 1200 2, 1, 3 LP 3
CRD,NTWK,50G
,SP,CX5,EN,ML
X,L,Z
Mellanox NIC: 50Gb 1500 2, 1, 3 LP 3
CRD,NTWK,50G
,DP,CX5,EN,ML
X,L,Z
Mellanox NIC: 50Gb 1600 2, 1, 3 LP 3
