Table 30. System board jumpers and connectors (continued)
Item Connector Description
6. J_TPM TPM
7. SIG_PWR_0 (Rear BP) Backplane signal and power 0
8. LOM connector LOM connector
9. IDSDM/Internal USB
connector
IDSDM/Internal USB connector
10. MB_FRONT_VIDEO Front VGA
11. SIG_PWR_4 GPU power
12. SL8_CPU1_PA2 PCIe/NVMe connector 8
13. IO_RISER1 (CPU1) Riser 1
14. SL7_CPU1_PB2 PCIe/NVMe connector 7
15. J_PS1_1U PSU1
16. BOSS_CARD_PWR BOSS card power
17. RGT_CP Right control panel
18. PWRD_EN PWRD_EN(Jumpers)
19. NVRAM_CLR NVRAM_CLR(Jumpers)
20. A16, A8, A15, A7, A14, A4,
A13, A3
DIMMs for processor 1 channels E, F, G, H
21. FAN_1U7/8 Fan 4
22. CPU1 Processor 1
23. FAN_2U4_1U5/6 Fan 3
24. SL4_CPU1_PA1_XA1 XGMI/NVMe connector 4
25. A1, A9, A2, A10, A5, A11,
A6, A12
DIMMs for processor 1 channels A, B, C, D
26. SIG_PWR_1 Backplane signal and power 1
27. SL3_CPU1_PB1_XB1 XGMI/NVMe connector 3
28. SL2_CPU2_PA3_XA2 XGMI/NVMe connector 2
29. B16, B8, B15, B7, B14, B4,
B13, B3
DIMMs for processor 2 channels E, F, G, H
30. FAN_1U3/4 Fan 2
31. SL1_CPU2_PB3_XB2 XGMI/NVMe connector 1
32. CPU2 Processor 2
33. FAN_2U1_1U1/2 Fan 1
34. B1, B9, B2, B10, B5, B11,
B6, B12
DIMMs for processor 2 channels A, B, C, D
35. LFT_CP Left control panel
36. J_PS2_1U PSU 2
37. SL5_CPU2_PA4_SA1 PCIe/NVMe/SATA connector 5
38. IO_RISER4 (CPU2) Riser 4
39. SL6_CPU2_PB4 PCIe/NVMe connector 6
38 Jumpers and connectors

Dell PowerFlex Custom Node R6525 Specifications

General

Processor	Up to 2x AMD EPYC 7002/7003 series processors, up to 64 cores per processor
Memory	32 DDR4 DIMM slots
Drive Bays	Up to 24 x 2.5" SAS/SATA (HDD/SSD)
RAID Support	PERC H745P
Networking	1GbE, 10GbE, 25GbE
Power Supply	1100W Platinum
