About Your System 17
3 iDRAC6 Enterprise
port (optional)
Dedicated management port for the
optional iDRAC6 Enterprise card.
4 VFlash media slot
(optional)
Connects an external SD memory card
for the optional iDRAC6 Enterprise card.
5 USB connectors (2) Connect USB devices to the system.
The ports are USB 2.0-compliant.
6 Ethernet connectors (2) Embedded 10/100/1000 NIC
connectors.
7 PCIe expansion card
slots using riser card
Riser 1
OR
Riser 2
Depending on the configuration, your
system may have either riser 1 or riser 2.
NOTE: See the Getting Started Guide
that ships with your system for more
information.
Connects four PCI Express Generation
2 expansion cards
NOTE: All four slots are x8 connectors.
Connects two PCI Express Generation
2 expansion cards.
NOTE: A General Purpose Computation
on Graphics Processing Units (GPGPU)
optimized configuration is available on
Riser 2.
8 System identification
connector
Connects the optional system status
indicator assembly through the
optional cable management arm.
Item Indicator, Button, or
Connector
Icon Description
book.book Page 17 Wednesday, March 3, 2010 10:37 AM
