Using the System Setup Program and UEFI Boot Manager 45
Memory Settings Screen
Processor Settings Screen
Option Description
System Memory Size Displays the system memory size.
System Memory Type Displays the system memory type.
System Memory Speed Displays the system memory speed.
Video Memory Displays the video memory size.
System Memory Testing
(Enabled default)
Specifies whether system memory tests are run at system
boot. Options are Enabled and Disabled.
Memory Operating Mode This field displays the type of memory operation if a
valid memory configuration is installed. When set to
Optimizer Mode, the memory controllers run
independently of each other for improved memory
performance. When set to Mirror Mode, memory
mirroring is enabled. When set to Advanced ECC
Mode, two controllers are joined in 128-bit mode
running multi-bit advanced ECC. For information about
the memory modes, see "System Memory" on page 82.
NOTE: The Spare Mode option may not be present
on all systems.
Node Interleaving
(Disabled default)
If this field is Enabled, memory interleaving is supported
if a symmetric memory configuration is installed. If
Disabled, the system supports Non-Uniform Memory
architecture (NUMA) (asymmetric) memory
configurations.
NOTE: The Node Interleaving field must be set to Disabled
when using Mirror mode.
Option Description
64-bit Specifies if the processor(s) support 64-bit extensions.
Core Speed Displays the processor clock speed.
Bus Speed Displays the processor bus speed.
book.book Page 45 Wednesday, March 3, 2010 10:37 AM
