Dell PowerVault NX3100 User Manual

Using the System Setup Program and UEFI Boot Manager 47
SATA Settings Screen (Optional)
Boot Settings Screen
Option Description
SATA controller
(ATA Mode default)
ATA Mode enables the integrated SATA controller. RAID
Mode enables the integrated SATA controller to RAID
mode. Off disables the controller.
NOTE: When set to RAID mode, all ports are set to OFF.
Port A
(Auto default)
Auto enables BIOS support for the device attached to
SATA port A. Off disables BIOS support for the device.
Port B
(Off default)
Auto enables BIOS support for the device attached to
SATA port B. Off disables BIOS support for the device.
Port C
(Off default)
Auto enables BIOS support for the device attached to
SATA port C. Off disables BIOS support for the device.
Port D
(Off default)
Auto enables BIOS support for the device attached to
SATA port D. Off disables BIOS support for the device.
Port E
(Off default)
Auto enables BIOS support for the device attached to
SATA port E. Off disables BIOS support for the device.
Option Description
Boot Mode
(BIOS default)
CAUTION: Switching the boot mode could prevent
the system from booting if the operating system was
not installed in the same boot mode.
If the system operating system supports UEFI, you can
set this option to UEFI. Setting this field to BIOS allows
compatibility with non-UEFI operating systems.
NOTE: Setting this field to UEFI disables the Boot
Sequence, Hard-Disk Drive Sequence, and USB Flash Drive
Emulation Type fields.
Boot Sequence If Boot Mode is set to BIOS, this field indicates to the
system the location of the operating system files needed
for startup. If Boot Mode is set to UEFI, you can access
the UEFI boot manager utility by rebooting the system
and pressing F11 when prompted to do so.
book.book Page 47 Wednesday, March 3, 2010 10:37 AM
