Dell PowerVault TL2000 Attachment Instructions

CONTENTS
EXECUTIVE SUMMARY 3
INTRODUCTION 3
iSCSI SAN SOLUTIONS 4
STEP-BY-STEP 4
NETWORK SETTINGS 6
STORAGE TARGETS : TL2000 / TL4000 9
CONFIGURING AN MD3000i 9
BACKUP EXEC 12 FOR WINDOWS SERVER INSTALLATION 10
SUMMARY 10
FIGURES
FIGURE 1 : Microsoft’s iSCSI Initiator 5
FIGURE 2 : IP Address 6
FIGURE 3 : iSCSI Targets 6
FIGURE 4 : Target Log On 6
FIGURE 5 : Network Connections 7
FIGURE 6 : Local Area Connection Properties 7
FIGURE 7 : IP Properties 7
FIGURE 8 : Select Network Adapter 8
FIGURE 9 : Jumbo Frames Settings 8
FIGURE 10 : PowerConnect 9
FIGURE 11 : General Settings 9
FIGURE 12 : Copy Files 9
FIGURE 13 : TL2000 / TL4000 1Gb iSCSI to SAS Bridge 10
FIGURE 14 : Set IP Address and Frame Size 10
FIGURE 15 : Configure iSCSI Settings 11
FIGURE 16 : Configure Host Ports 11
FIGURE 17 : Environment Check Screen 12
FIGURE 18 : Licensing Screen 13

Dell PowerVault TL2000 Specifications

General

Number of Drives	1 or 2
Number of Slots	24
Type	Tape Library
Drive Types	LTO-4, LTO-5, LTO-6
Interface	SAS, Fibre Channel
Dimensions	8.68 in (22.05 cm) x 19.0 in (48.26 cm) x 30.0 in (76.2 cm)
Tape Drive Compatibility	LTO-4, LTO-5, LTO-6
Power Supply	Redundant power supplies optional
Operating Temperature	50°F to 95°F (10°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
