Appendix 119
Display
Type (active-matrix TFT) XGA
Dimensions:
Height 184 mm (7.26 inches)
Width 246 mm (9.7 inches)
Diagonal 307 mm (12.1 inches)
Maximum resolutions 1024 x 768 at 16.8 million colors
Response time (typical) 50-ms rise and fall (maximum)
Refresh rate 60 Hz
Operating angle 0° (closed) to 180°
Viewing angles:
Horizontal ± 40°
Vertical +10°/–30°
Pixel pitch 0.28 mm horizontal x 0.28 mm vertical
Power Consumption:
Panel with backlight (typical) 4.5 W
Controls brightness can be controlled through
keyboard shortcuts
Keyboard
Number of keys 84 (U.S. and Canada); 85 (Europe);
88(Japan); 86 (Brazil)
Key travel 2.4 mm (0.09 inch)
Key spacing 18.0 mm (.73 inch)
Layout QWERTY/AZERTY/Kanji
