A Tour of Your Computer 31
Bottom View
BATTERY LATCH RELEASE — Releases the battery. See "Removing a Battery" on page 47 for
instructions.
BATTERY CHARGE GAUGE — Provides information on the battery charge. See "Charging the
Battery" on page 47.
battery charge gauge
battery/battery bay
docking device connector
memory module/ Mini
PCI card/modem cover
battery latch
release
Service Tag
battery latch
release
