Camera module
Removing the camera module
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the base cover.
4. Remove the 4G WWAN card or 5G WWAN card, as applicable.
5. Remove the WLAN card.
6. Remove the display assembly.
7. Remove the display bezel.
8. Remove the display panel.
About this task
The following images indicate the location of the camera module and provide a visual representation of the removal procedure.
110 Removing and installing Field Replaceable Units (FRUs)
