Dell Precision 3580 User Manual

External ports
The following table lists the external ports of your Precision 3580.
Table 7. External ports
Description Values
Network port
One RJ-45 port
USB ports
● Two Thunderbolt 4 port with DisplayPort Alt Mode/USB
Type-C/USB4/Power Delivery
NOTE: You can connect a Dell Docking Station to this
port. For more information, search in the Knowledge
Base Resource at www.dell.com/support.
● One USB 3.2 Gen 1 port with PowerShare
● One USB 3.2 Gen 1 port
Audio port
One Universal audio port
Video port
One HDMI 2.0 port
Media-card reader
One smart card reader slot (optional)
Power-adapter port
Type-C adapter
Security-cable slot
One security-cable slot (wedge-shaped)
Internal slots
The following table lists the internal slots of your Precision 3580.
Table 8. Internal slots
Description Values
M.2
● One M.2 2230 slot for WiFi and Bluetooth combo card
● One M.2 2230/2280 slot for solid-state drive
● One M.2 2230 slot for solid-state drive
● One M.2 3042/3052 slot for WWAN (optional)
NOTE: To learn more about the features of different
types of M.2 cards, search in the Knowledge Base
Resource at www.dell.com/support.
Ethernet
The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Precision 3580.
Table 9. Ethernet specifications
Description Values
Model number
Intel I219-LM
Transfer rate
10/100/1000 Mbps
Specifications of Precision 3580 19

Dell Precision 3580 Specifications

General

Processor	13th Gen Intel Core i5/i7/i9 or Xeon
Display	15.6-inch, FHD 1920 x 1080, 60 Hz, Anti-Glare, Non-Touch
Graphics	NVIDIA RTX A500
Memory	Up to 64GB DDR5
Storage	Up to 4TB PCIe NVMe SSD
Operating System	Windows 11 Pro
Ports	2 x Thunderbolt 4, 2 x USB 3.2 Gen 1
Wireless	Wi-Fi 6E, Bluetooth 5.2
Camera	1080p
Battery	4 Cell, 64 Wh
Weight	Starting at 1.79 kg (3.95 lbs)
