About this task
The figure indicates the location of the keyboard lattice and provides a visual representation of the removal procedure.
Steps
1. Using a plastic scribe, pry the top edge of the keyboard lattice starting from the recess points and working your way around
the sides and bottom edge.
2. Remove the keyboard lattice from the keyboard.
Installing the keyboard lattice
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the keyboard lattice and provides a visual representation of the installation procedure.
Removing and installing components
41
