Dell Precision 7760 - Palm Rest Removal and Installation

NOTE: For computers shipped with IR camera configuration, connect the display cable and IR camera cable. Carefully
route the cables between the hinges and the inside of the middle cap.
Next steps
1. Install the power-adapter port.
2. Install the system board.
3. Install the heat-sink assembly.
4. Install the keyboard.
5. Install the keyboard lattice.
6. Install the SIM card.
7. Install the primary memory.
8. Install the WWAN card.
9. Install the WLAN card.
10. Install the secondary memory.
11. Install the primary M.2 SSD.
12. Install the battery.
13. Install the base cover.
14. Install the secondary M.2 SSD.
15. Install the SD card.
16. Follow the procedure in after working inside your computer.
Palm rest
Removing the palmrest
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the SD card.
3. Remove the secondary M.2 SSD.
4. Remove the base cover.
5. Remove the battery.
6. Remove the SIM card.
7. Remove the secondary memory.
8. Remove the WLAN card.
9. Remove the WWAN card.
10. Remove the primary M.2 SSD.
11. Remove the keyboard lattice.
12. Remove the keyboard.
13. Remove the power button board or power button board assembly with fingerprint reader.
14. Remove the smart-card reader.
15. Remove the touchpad buttons.
16. Remove the power button or power button assembly with fingerprint reader.
17. Remove the SD card reader.
18. Remove the GPU power cable.
19. Remove the GPU card.
20. Remove the primary memory.
21. Remove the heat-sink assembly.
22. Remove the inner frame.
23. Remove the system board.
24. Remove the power-adapter port.
25. Remove the speakers.
26. Remove the middlecap.
27. Remove the display assembly.
