Palm Rest Assembly: Dell Precision M6400 Service Manual
file:///T|/htdocs/systems/wsm6400/en/sm/palmrest.htm[11/16/2012 10:27:08 AM]
CAUTION: Before working inside your computer, read the safety information that shipped with your
computer. For additional safety best practices information, see the Regulatory Compliance Homepage on
www.dell.com at: www.dell.com/regulatory_compliance.
1. Place the palm rest on the computer, then gently press around the edges to firmly snap the palm rest to the base
assembly.
2. Connect the biometer, contactless smart card, touchpad, speaker, and power cables to the system board.
3. Replace the nine M2 x 3-mm screws in the holes labeled "P".
4. Replace the keyboard (see Replacing the Keyboard).
5. Replace the LED cover (see Replacing the LED Cover
).
6. Replace the display assembly (see Replacing the Edge-to-Edge Display
or Replacing the Display Assembly).
7. Turn the computer upside down, and replace the four M2.5 x 8-mm screws in the holes labeled "P".
8. Replace the optical drive (see Replacing the Optical Drive
).
9. Replace the secondary hard drive (see Replacing the Secondary Hard Drive (HDD2)
).
10. Replace the base assembly cover (see Replacing the Base Assembly Cover
).
11. Follow the procedures in After Working on Your Computer
.
