Dell Precision M6400 - Removing the Display Panel

LED and CCFL Displays: Dell Precision M6400 Service Manual
file:///T|/htdocs/systems/wsm6400/en/sm/displayb.htm[11/16/2012 10:27:02 AM]
1 display bezel 2 M2.5 x 5-mm screws (2)
3 hinges 4 display cover
5. Follow the procedures in After Working on Your Computer
.
Removing the Display Panel
CAUTION: Before working inside your computer, read the safety information that shipped with your
computer. For additional safety best practices information, see the Regulatory Compliance Homepage on
www.dell.com at: www.dell.com/regulatory_compliance.
1. Follow the instructions in Before Working on Your Computer
.
2. Remove the display bezel (see Removing the Display Bezel
).
3. Move the antenna cables slightly out of the way to remove the eight
M2 x 3-mm screws from the display panel.
4. Remove the two M2 x 3-mm screws from bracket on the display panel.
