Dell S4148F-ON Series User Manual

LED behavior
The following S4100–ON Series switch LED behavior displays during open networking installation environment (ONIE) operations:
Figure 5. S4128F-ON I/O-side LEDs
1 QSFP28 port activity LEDs 2 Link (left), activity (right) port LEDs
3 Master LED 4 System LED
5 Power LED 6 Fan LED
7 Locator LED/System beacon 8 Stack ID
Figure 6. S4148F-ON I/O-side LEDs
1
QSFP28 port activity LEDs 2 Link/activity port LEDs
3 Master LED 4 System LED
5 Power LED 6 Fan LED
7 Locator LED/System beacon 8 Stack ID
10 S4100–ON Series switch

Dell S4148F-ON Series Specifications

General

Uplink Ports	6 x 40GbE QSFP+
Switching Capacity	1.44 Tbps
Power Supply	Dual, Hot-swappable
Airflow	Front-to-back or back-to-front
Product Type	Switch
Form Factor	Rack-mountable
Flash Memory	16GB
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Model	S4148F-ON
Category	Switch
Storage Temperature	-40°C to 70°C
AC Input Frequency	50/60 Hz
Latency	800ns
Rack Units	1
Jumbo Frame Support	9, 216 bytes
Software	Dell EMC Networking OS10
CPU	Intel x86
RAM	8GB
Operating System	Dell EMC OS10
Management	CLI, SNMP
Dimensions (W x D x H)	440 x 440 x 44 mm
Humidity	5% to 95% non-condensing
Ports	48 x 10GbE SFP+
Operating Humidity	10% to 90% (non-condensing)
