S4100–ON Series installation
To install the S4100–ON Series (S4128F-ON and S4148F-ON), complete the installation procedures in the order presented in this section.
Always handle the S4100–ON Series switch and its components with care. Avoid dropping the switch or any eld replaceable units (FRUs).
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-preventive wrist or heel ground strap when
handling the S4100–ON Series switch and its components. As with all electrical devices of this type, take all the necessary safety
precautions to prevent injury when installing this switch.
NOTE: For more information, see the Open Networking Hardware Diagnostic Guide .
Topics:
• Unpack the switch
• Rack or cabinet installation
• ReadyRails installation
• S4100-ON Series installation
• Optics installation
• Switch power-up
• After switch installation
Unpack the switch
NOTE
: Before unpacking the switch, inspect the container and immediately report any evidence of damage.
When unpacking the S4100–ON Series switch, make sure that the following items are included:
• One S4100–ON Series (S4128F-ON and S4148F-ON) switch
• One RJ-45 to DB-9 female cable
• Two sets of rail kits, no tools required
• Two PSUs
• Four fan units
• Two country- and region-specic AC power cords
• Dell S4100–ON Series Setup Guide
• Safety and Regulatory Information
• Warranty and Support Information
Unpack
1 Place the container on a clean, at surface and cut all straps securing the container.
2 Open the container or remove the container top.
3 Carefully remove the switch from the container and place it on a secure and clean surface.
4 Remove all packing material.
4
