Configuring LogWatcher on the Domain Controller
The DCConfig.xml file is used for configuration. The following XML snippet shows how the data is stored in the
DCConfig.xml file:
<SONICWALL_LOG_WATCHER>
<AGENTS>
<AGENT>
<IP_ADDRESS>10.50.173.252</IP_ADDRESS>
<PORT_NO>2259</PORT_NO>
</AGENT>
</AGENTS>
<SEC_KEY>abc123</SEC_KEY>
<IGNORE_TIME>10</IGNORE_TIME>
<LOG_LEVEL>0</LOG_LEVEL >
<LW_PORT_NO>2259</LW_PORT_NO>
<DC_IP>10.50.173.54</DC_IP>
</SONICWALL_LOG_WATCHER>
The above data fields are defined as follows:
Configuring/Enabling LogWatcher in Directory Services
Connector
To configure LogWatcher in Directory Services Connector, perform the following steps:
1 In the DSC Configuration Tool, right-click the SSO Agent or use the Actions menu to open the Properties
page of the SSO Agent.
2Select DC Security Log in the Query Source drop-down list.
3 Select the Add LogWatcher Support checkbox.
4 Enter the LogWatcher Port number (default is 2259).
5 Enter the LogWatcher Shared Key.
Table 1. LogWatcher data fields
IP_ADDRESS IP address of the SSO Agent
PORT_NO Port number of the SSO Agent for receiving the UDP packet
SEC_KEY Secret Key for encrypting the packet data
IGNORE_TIME (in seconds) Used to avoid successive user logon/logoff; default value is 10 seconds
LOG_LEVEL Can have any of three values:
• 0 (NOLOGS) - Do not log any messages
• 1 (ERRORSONLY) - Log only Error messages
• 2 (DIAGNOSTIC) - Log all messages
LW_PORT_NO LogWatcher port for sending the UDP packet
DC_IP IP address of the Domain Controller
NOTE: The SSO port number and shared key in the DCConfig.xml file on the Domain Controller
must be the same as the LogWatcher Port number and LogWatcher Shared Key.
