Dell Studio 1535 - Replacing the System Board Assembly


1. Replace the system board in position.

2. Replace the four screws on the top of the system board.

3. Connect the system board cable.

4. Follow the steps in Removing the System Board Assembly in reverse order.
Back to Contents Page

CAUTION: Before you begin the following procedure, follow the safety instructions that shipped with your computer.
NOTICE: Ensure that any loose cables do not get caught beneath the system board.
