Dell U3425WE - Electrical Specifications

24  │  About your monitor
Thunderbolt™ out for daisy chain
Maximum external monitor resolution that can be supported
3440 x 1440 at 120 Hz
NOTE: The maximum resolution of 3440 x 1440 at 120 Hz can only be
produced with Thunderbolt™ DP-ALT 1.4 or DP 1.4. The maximum
resolution of HDMI is 3440 x 1440 at 100 Hz.
Electrical specifications
Model U3425WE
Video input signals • HDMI 2.1 (TMDS)*/DisplayPort 1.4**, 600 mV for
eac
h differential line, 100 ohm input impedance per
differential pair
• Thunderbolt™ 4/USB-C DP Input (DP-Alt Mode),
600 mV for each differential line, 85 ohm input
im
pedance per differential pair
AC input voltage/
fr
equency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 3.2 A
(typical)
Inrush current • 120 V: 40 A (Max.) at 0°C (cold start)
• 240 V: 80 A (Max.) at 0°C (cold start)
Power consumption • 0.3 W (Off mode)
1
•0.5 W (Standby mode)
1
• 1.9 W (Networked Standby mode)
1
•31.5 W (On mode)
1
• 250 W (Max.)
2
•29.3 W (P
on
)
3
•99 kWh (TEC)
3
*Supports up to WQHD 3440 x 1440 100 Hz TMDS as per specified in HDMI 2.1.
**HBR3/DisplayPort 1.4/DP audio is supported.
OSD Display Info:
Li
nk rate (current)
