Dell U3425WE - Connecting the Thunderbolt 4 Passive Cable

48  │  Setting up the monitor
Connecting the USB Type-A to USB Type-C cable
NOTE: The USB connection offers USB data transfer only in this
scenario.
NOTE: Remove the rubber plug when using USB Type-C upstream port.
NOTE: Use the USB Type-A to USB Type-C cable shipped with your
monitor only.
Connecting the Thunderbolt™ 4 passive cable
NOTE: Use the Thunderbolt™ 4 passive cable shipped with your
monitor only.
• This port supports DisplayPort Alternate Mode (DP1.4 standard only).
• The Thunderbolt™ 4 power delivery compliant port (PD Version 3.1) delivers
up t
o 90 W of power.
• If your notebook requires more than 90 W to operate and the battery is
dr
ained, it may not be powered up or charged with the USB PD port of this
monitor.
• Thunderbolt™ 4 is not supported on versions of Windows prior to Windows 10.
