32 │ About your monitor
Universal Serial Bus (USB) interface
This section gives you information about the USB ports that are available on the
monitor.
Transfer speed Data rate Maximum power supported*
Super speed 10 Gbps 4.5 W
High speed 480 Mbps 4.5 W
Full speed 12 Mbps 4.5 W
Super speed USB 10 Gbps (USB 3.2 Gen2)
*Up to 2 A on USB downstream port (with
battery icon) with BC1.2
compliance devices or normal USB devices.
USB Type-C Description
Data Super speed USB 10 Gbps (USB 3.2 Gen2)
Thunderbolt™ 4 Description
Video DisplayPort 1.4 (passive cable)
Data USB 2.0, USB 3.2
Power Delivery (PD) Thunderbolt™ 4 upstream port: up to 90 W (typical)
Thunderbolt™ 4 downstream port: up to 15 W (typical)
NOTE: This monitor is super speed USB 10 Gbps (USB 3.2 Gen2)
compatible.
USB Type-C
Thunderbolt™ 4
NOTE: USB Type-C video requires a Type-C Alternate Mode capability
computer.
NOTE: To support USB Type-C Alternate Mode, please ensure that the
Source computer has Alternate Mode capability.
